Description
Product Description
Phase
- Single-Phase
Topology
- Transformer less
Max Efficiency
- 97,8%
Battery supported
- None
Input PV Max Power
- 4.5KW
Input PV Max Voltage
- 500V
Input Max Current
- 15A
Input Max Short Circuit Current
- 20A
Input PV Start Voltage
- 70V
MPPT Operating Voltage
- 50V-490V
No MPPTs
- 1
Max No PV Strings
- 1
Output Rated Voltage
- 220V / 230V, L+N+PE
Output Rated Power
- 3KW
Output Max Apparent Power
- 3.3KVA
Output Max Current
- 15A
Protections
- DC switch
Anti-islanding
AC overcurrent
AC short circuit
DC reverse connection
Surge Arrester (AC Type III)
Insulation detection
Leakage current
Parallel Connection
- Yes
IP Rating
- IP65
Cooling
- Natural(Passive)
Display
- LED + APP
Noise level
- <30dB
Integrated Communication
- Bluetooth, RS485 (CT / Meter)
External Communication Modules
- WiFi (included)
Optional: GPRS, 4G, LAN
Others
- Night Self Consumption <1W
Operating Temperature -25°C – 60°C
Relative Humidity 0 – 100%
Max Operating Altitude 4000m
Remote configuration and upgrade
Dimensions (W x H x D)
- 320 x 344 x 137 mm
