nJoy Ascet 6K-120/1P2T2 Single-phase hybrid solar inverter 6KW / 6KW Remote configuration and upgrade SIH12006L062ACCU0B
145,200 L
Ka stok
Ka stok
12
People watching this product now!
-
Dërgesat në Tiranë
Brenda qytetit të Tiranës korieri vjen brenda ditës.
24 Orë
L
-
Dërgesat në Gjithë Shqipërinë
Në qytetet e tjera të Shqipërisë posta arrin brenda 1 ose 2 ditëve.
1-2 Ditë
L
-
Garanci 12 muaj
-
Mundësi kthimi në 30 ditë
Mënyrat e Pagesës:
Description
Product Description
Phase
Single-Phase
Topology
Transformerless
Max Efficiency
97,3%
Battery Mode Efficiency
94,0%
Battery supported
48V Lithium or Lead Acid
Input PV Max Power
9KW
Input PV Max Voltage
550V
Input PV Rated Voltage
360V
Input Max Current
30A (2x15A)
Input Max Short Circuit Current
40A (2x20A)
Input PV Start Voltage
90V
MPPT Operating Voltage
70V-520V
No MPP
Ts2
Max No PV Strings
2 (1/1)
Battery Voltage Range
40V-60V
Battery Charge/Discharge Power
5KW / 5KW
Battery Charge/Discharge Current
120A / 120A
Output Rated Voltage
220V / 230V, L+N+PE
Output Rated Power
5KW
Output Max Apparent Power
5.5KVA
Output Max Current
25A
ProtectionsDC switch
Anti-islanding
AC overcurrent
AC short circuit
DC reverse connection
Surge Arrester (AC & DC Type III)
Insulation detection
Leakage current
Anti-islanding
AC overcurrent
AC short circuit
DC reverse connection
Surge Arrester (AC & DC Type III)
Insulation detection
Leakage current
Parallel Connection
Yes
IP Rating
IP65
Cooling
Natural
Noise level
<35dB
Display
LED + APP
Integrated Communication
Bluetooth, RS485 (BMS / CT / Meter / DRM)
External Communication ModulesWiFi + Smart Meter (included)
Optional: GPRS, 4G, LAN
Optional: GPRS, 4G, LAN
OthersEPS (Emergency Power Supply) circuit for Battery mode
Battery Charging from PV Only or from PV + Grid
Self Adaptation to BMS
Transfer Time from/to Battery 10ms (typical) / 20ms (max)
Operating Temperature -25°C – 60°C
Relative Humidity 0 – 100%
Max Operating Altitude 4000m
Remote configuration and upgrade
Battery Charging from PV Only or from PV + Grid
Self Adaptation to BMS
Transfer Time from/to Battery 10ms (typical) / 20ms (max)
Operating Temperature -25°C – 60°C
Relative Humidity 0 – 100%
Max Operating Altitude 4000m
Remote configuration and upgrade
Dimensions (W x H x D)515 x 485 x 175 mm
Weight24.6 Kg
Full specifications click here
