nJoy Ascet 10K-50/3P2T3 Three-phase hybrid solar inverter 10KVA / 10KW Remote configuration and upgrade SIH32010H113ACCU0B

Name: nJoy Ascet 10K-50/3P2T3 Three-phase hybrid solar inverter 10KVA / 10KW Remote configuration and upgrade SIH32010H113ACCU0B - Apfel Online Store Tirana
SKU: AE-SIH32010H113ACCU0B
Price: 209000 ALL
Availability: InStock

SKU: AE-SIH32010H113ACCU0B

209,000 L

Ka stok

Add to compare

Add to wishlist

18 People watching this product now!

Dërgesat në Tiranë

Brenda qytetit të Tiranës korieri vjen brenda ditës.

24 Orë

L

Dërgesat në Gjithë Shqipërinë

Në qytetet e tjera të Shqipërisë posta arrin brenda 1 ose 2 ditëve.

1-2 Ditë

L

Garanci 12 muaj

Më shumë detaje

Mundësi kthimi në 30 ditë

Më shumë detaje

Mënyrat e Pagesës:

Description

Product Description

Product specs

GS15949515902520

PNSIH32010H113ACCU0B

PhaseThree-Phase

TopologyTransformerless

Max Efficiency98.4%

Battery Mode Efficiency98,0%

Battery supportedHigh Voltage LifePO4 or Lead Acid

Input PV Max Power15KW

Input PV Max Voltage1000V

Input Max Current20A (MPPT 1) / 30A (MPPT 2)

Input Max Short Circuit Current30A (MPPT 1) / 40A (MPPT 2)

Input PV Start Voltage150V

MPPT Operating Voltage160V-950V

No MPPTs2

Max Single Phase Power

5000W

Max No PV Strings3 (1/2)

Battery Voltage Range120V-600V

Battery Charge/Discharge Power15KW / 11.3KW

Battery Charge/Discharge Current50A / 50A

Output Rated Voltage380V / 400V / 415V, 3W+N+PE

Output Rated Power10KW

Output Max Apparent Power11KVA

Output Max Current3 x 16.7A

Protections

Protection category Class 1

DC switch Support

Anti-islanding protection

Support AC overcurrent protection

Support DC/AC overvoltage protection

DC Type II, AC Type III

DC reverse connection

Support surge arrester DC type ll, AC type ll

Insulation detection

Support leakage current protection

Support GFCI

Support AC

Short circuit protection support

Arc-Fault Circuit Interrupter (AFCI)

IP RatingIP65

CoolingNatural

DisplayLED + APP

Integrated CommunicationBluetooth, RS485/CAN (BMS),RS485 (For meter), DRM, 2x DI (1 RMO), 2x DO, WIFI Module

External Communication Modules

Optional: GPRS / LAN

Others

PV connection way MC4/H4

Self-Adaptation to BMS

Operating Temperature -25°C – 60°C

Relative Humidity 0 – 100%

Max Operating Altitude 4000m

Remote configuration and upgrade

Dimensions (W x H x D)

560 x 218 x 580 mm

Weight

32.85 kg

Specification

Brand

Processor

RAM

Storage

Graphics

Display

Connectivity

Features

Battery

General
