IPC-HFW1539DTK1-SAW-IL-0280B 5MP Bullet Dual Light Wi-Fi Audio Speaker Bluetooth WiFi

Product Description

Camera
Image Sensor 1/2.7″ CMOS
Max. Resolution 2880 (H) × 1620 (V)
Min. Illumination 0.007 lux@F1.6 (Color, 30 IRE)
0.0007 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on)
Illumination Distance Up to 30 m (98.43 ft) (IR)
Up to 30 m (98.43 ft) (Warm light)
Illuminator Number 1 (Multi-core (IR + warm) light)
Angle Adjustment Tilt: 0°–90°
Rotation: 0°–360°
Lens Type Fixed-focal
Focal Length 2.8 mm;3.6 mm
Max. Aperture F1.6
Field of View 2.8 mm: H: 104°; V: 56°; D: 124°
3.6 mm: H: 89°; V: 48°; D: 104°
Intelligence
Human Detection Yes
Vehicle Detection Yes
Audio and Video
Video Compression H.264B; H.264; H.264H; H.265;
Video Frame Rate
Main stream: 2880 × 1620@(1–25/30 fps)
sub stream: 640 × 360@(1–25/30 fps)
*The values above are the max. frame rates of each
stream; for multiple streams, the values will be
subjected to the total encoding capacity.
Video Bit Rate H.264: 32 kbps–6144 kbps
H.265: 32 kbps–6144 kbps
Day/Night Auto(ICR)/Color/B/W
WDR DWDR
Motion Detection OFF/ON (4 areas, rectangular)
Image Rotation 0°/180°
Built-in MIC Yes, built-in Mic
Audio Compression G.711a; G.711Mu; PCM
Network
Network Port RJ-45 (10/100 Base-T)
Wi-Fi IEEE 802.11b/g/n/ax 2.4000–2.4835 GHz, 2.4 G,
EIRP≤20 dBm
Wi-Fi Pairing Bluetooth pairing
Interoperability ONVIF (Profile S & Profile G & Profile T); CGI
Storage Micro SD card (support max. 256 GB)
Management Software Smart PSS Lite; DSS; DMSS
Mobile Client Android;iOS
Function
Abnormal Sound Alarm Yes
General
Certifications CE
Power Supply 12 VDC (±30%)
Power Consumption Basic: 2.4 W (12 VDC);
Max.: 4.3 W (12 VDC)
Operating Temperature –30 °C to +50 °C (–22 °F to +122 °F)
Operating Humidity ≤95% (RH), non-condensing
Protection IP67
Camera Button Reset button
Casing Material Metal + plastic
Product Dimensions 172.4 mm × 83.3 mm × 75.0 mm (6.79″ × 3.28″ ×
2.95″) (L × W × H)
Net Weight 0.3 kg (0.66 lb)
