Easy UPS 3M 80kVA 400V 3:3 UPS 4 internal 9Ah modular battery strings expandable to 6 Start-up 5×8 E3MUPS80KHB1S

SKU: AE-E3MUPS80KHB1S

2,362,490 L

S’ka stok

S’ka stok

13 People watching this product now!
  • Dërgesat në Tiranë

Brenda qytetit të Tiranës korieri vjen brenda ditës.

24 Orë

 L

  • Dërgesat në Gjithë Shqipërinë

Në qytetet e tjera të Shqipërisë posta arrin brenda 1 ose 2 ditëve.

1-2 Ditë

 L

  • Garanci 12 muaj
  • Mundësi kthimi në 30 ditë

Mënyrat e Pagesës:

Description

Product Description

Main Input Voltage 400 V 3 phases
Main Output Voltage 400 V 3 phases
Rated power in W 80 kW
Rated power in VA 80 kVA
Provided equipment Dust filter
Installation guide
Start-up service
Batteries & Runtime
Battery type VRLA
Battery voltage 240 V
Number of battery filled slots 0
Number of battery free slots 0
Max current discharge 222 A
Physical
Colour White (RAL 9003)
height 197 cm
Width 60 cm
Depth 100 cm
Net weight 771 kg
USB compatible Yes
Input
Maximum input current 146 A
Max short time withstand current 10 kA
Input harmonic distortion Less than 3 % for full load
Load power factor 0.5 leading to 0.5 lagging without derating
Input Power Factor at Full Load 0.99
Input voltage limits 342…477 V
Number of input connectors 1 hard wire 5-wire (3P + N + E)
Network frequency 40…70 Hz
Output
Maximum configurable power in VA 80 kVA
Maximum configurable power in W 80 kW
Output frequency 50 Hz sync to mains
60 Hz sync to mains
Harmonic distortion Less than 3 %
Output harmonic distortion < 3% linear load and < 5% non-linear load
Output overload operation 10 minutes at 125% and 60 seconds at 150%
UPS type Double conversion online
Wave type Sine wave
bypass type Built-in static bypass
Conformance
product certifications CE
EAC
RCM
Environmental
Ambient air temperature for operation 0…40 °C
Relative humidity 0…95 % non-condensing
Operating altitude 0…1500 ft
Ambient air temperature for storage -15…40 °C
Storage Relative Humidity 0…95 % non-condensing
Storage altitude 0.00…4572.00 m
Acoustic level 65 dBA
Heat dissipation 14850 Btu/h
IP degree of protection IP20
Communications & Management
control panel Touch screen LCD user interface
