Access Control Extension Module DEE1010B

Product Description

Core Features

• Access Control Expansion: Works alongside access control terminals or door stations to manage additional locks, input from card readers, door sensors, and exit buttons.

• Lock Outputs: Supports both Normally Open (NO) and Normally Closed (NC) lock control options.

• User Inputs: Can connect to a door-open (exit) button and supports door status detection.

Technical Basics

• Communication Interface: Uses RS-485 bus for communication with the main system.

• Card Input: Integrates card swipe input functionality when paired with a card reader.

• Indicators: Provides multiple LED indicators showing power status, operational (running) status, and unlock signal status.

Power & Consumption

• Supply Voltage: 12 V DC (±10% tolerance).

• Power Usage: Very efficient — around ≤ 0.5 W in standby and up to 1 W during actual operation.

Physical & Environmental

• Dimensions: Approximately 58 mm × 51 mm × 24.5 mm (width × depth × thickness).

• Weight: Roughly 0.56 kg (560 g).

• Operating Conditions: Functions reliably between –10 °C and +60 °C, and handles humidity levels from 10% to 90% (non-condensing).

Usage & Installation

• Ideal for setups requiring a secondary door or lock (e.g., in security portals or mantraps).

• Fits into standard 86-type gang boxes for neat, protected installation.

• Connects seamlessly with outdoor intercom stations (VTO series) and indoor control systems, enhancing access control capabilities.
