DELL PRECISION 3630 – RAM 32GB – PROC XEON E-2186G – SSD 512GB – QUADRO P620

📦 Key Specifications

• Model: Dell Precision 3630 Tower Workstation
• Processor: Intel Xeon E‑2186G
  • 6 cores / 12 threads
  • Base frequency: 3.8 GHz
  • Turbo boost up to 4.7 GHz
  • 12 MB Smart Cache
• Memory (RAM): 32 GB DDR4 (ECC or Non-ECC), upgradable up to 128 GB across 4 DIMM slots
• Storage: 512 GB PCIe NVMe M.2 SSD
• Graphics: NVIDIA Quadro P620 – 2 GB GDDR5 (professional-grade GPU for CAD, DCC, and 3D modeling)
• Integrated Graphics (optional): Intel UHD Graphics P630 (disabled when Quadro GPU is active)
• Chipset: Intel C246 – workstation-class reliability and manageability

🖥️ Expandability & Connectivity

• PCIe Slots:
  • 1 × PCIe x16 (full-height)
  • 2 × PCIe x4 (open-ended)
  • 1 × PCIe x1
• Storage Bays:
  • 1 × M.2 2280 SSD
  • Multiple 2.5″ and 3.5″ drive bays (supports mixed drive types)
• Front I/O Ports:
  • USB 2.0, USB 3.1 Gen 1, USB-C
  • Headphone/microphone combo jack
• Rear I/O Ports:
  • USB 2.0 and USB 3.1 Gen 1
  • PS/2 ports
  • RJ‑45 Ethernet
  • DisplayPort (via GPU)
  • Optional VGA, HDMI, or serial ports
  • Audio line-in/out
• Power Supply Options:
  • Available with 300 W, 460 W, or 850 W PSU (depending on configuration)

🎯 Use Cases

• Engineering and CAD: Ideal for AutoCAD, SolidWorks, and Revit
• Media and Content Creation: Suitable for Adobe Creative Suite, 3D rendering, and design
• Workstation Applications: Optimized for ISV-certified apps and stability under load
• Software Development and Data Analysis: Handles virtualization, compilers, and large datasets efficiently

⚙️ Upgrade Potential

• Memory: Expandable up to 128 GB for more demanding multitasking or virtualization
• Storage: Multiple M.2 and SATA drive slots available for additional SSDs or HDDs
• GPU: Can be upgraded to higher-end professional or consumer graphics cards
• Networking: Optional expansion cards for Wi‑Fi, Bluetooth, or additional Ethernet ports

✅ Summary

The Dell Precision 3630 Tower with Xeon E‑2186G, 32 GB RAM, 512 GB SSD, and Quadro P620 is a reliable and scalable workstation built for professionals. It provides strong performance for 3D modeling, engineering design, media creation, and complex workflows—along with excellent upgrade potential for long-term use.
